DELL DA305 6 IN 1 USB-C ADAPTER DOCKING STATION

KShs 25,999.00

Ports: 6-in-1 USB-C multiport adapter with HDMI 2.0 output supporting 4K at 60 Hz, 2x USB 3.2 Gen 1 Type-A ports at 5 Gbps, 1x USB 3.2 Gen 1 Type-C port at 5 Gbps with 15 W power delivery pass-through, 1x RJ45 Gigabit Ethernet port at 1 Gbps, and USB-C upstream connection.
Video Resolution: Single display output up to 3840 x 2160 at 60 Hz via HDMI 2.0 with HDCP 2.2 support.
Data Transfer: USB ports deliver 5 Gbps bandwidth with backward compatibility to USB 2.0.
Network: Integrated Realtek RTL8153 Ethernet controller providing 10/100/1000 Mbps wired connectivity.
Dimensions: 110 mm x 60 mm x 15 mm aluminum chassis weighing 85 grams.
Compatibility: Supports Windows 10/11, macOS, and Chrome OS with plug-and-play operation requiring no drivers for core functions.

Free delivery from KShs 100,000.00

Manufacturer warranty

0700 305 305

Bulk orders quoted

SKU 07MCF3 Category Power Solutions Brand: Dell

Description

Chassis: Precision-machined aluminum alloy enclosure measuring 110 mm length by 60 mm width by 15 mm height with matte black anodized finish and 85 gram total weight.
Connectors: USB-C male upstream plug integrated with 0.15 m cable length, female ports include HDMI 2.0 Type-A, dual USB 3.2 Gen 1 Type-A, USB 3.2 Gen 1 Type-C, and RJ45 Ethernet.

Output: HDMI 2.0 port supporting maximum resolution of 3840 x 2160 pixels at 60 Hz refresh rate with 8-bit color depth and HDCP 2.2 content protection.
Compatibility: Single display mode only with no daisy-chaining or MST support.

USB Bandwidth: All downstream USB ports operate at 5 Gbps SuperSpeed with UASP protocol support for storage devices.
Ethernet Controller: Realtek RTL8153 chipset delivering full-duplex 1 Gbps throughput with IEEE 802.3az energy efficiency.

Support: No integrated cameras or video capture hardware present in the adapter.

Power Delivery: USB-C downstream port provides up to 15 W (5 V/3 A) pass-through charging from host PD source with 100 W input capability on upstream.
Power Consumption: Maximum 4.5 W device draw excluding pass-through loads.

Drivers: No additional drivers required for Windows 10 version 1709 or later, macOS 10.15 or later; Ethernet uses native OS networking stack.

Upstream: USB 3.2 Gen 1 Type-C male connector supporting 5 Gbps data and up to 100 W PD input.
Downstream Ports: 1x HDMI 2.0, 2x USB 3.2 Gen 1 Type-A (5 Gbps), 1x USB 3.2 Gen 1 Type-C (5 Gbps, 15 W), 1x RJ45 1 Gbps Ethernet.

Finish: Available exclusively in matte black anodized aluminum with silver port legends.
