DJI RS 4 MINI

Description

Design & Build

• Materials: Aluminum alloy and composite construction with 795 g total weight.
• Dimensions Folded: 247 × 170 × 68 mm.
• Dimensions Unfolded: 247 × 230 × 90 mm.
• Mount: 1/4-inch-20 UNC screw with quick release plate.

Display

• Interface: No built-in display; full control via DJI Mimo app on paired smartphone.
• Status Indicators: LED indicators for mode, battery and connection status.

Performance

• Stabilization Axes: 3-axis brushless with ±0.01° precision.
• Payload: Maximum 2 kg tested with mirrorless cameras.
• Tracking: ActiveTrack 4.0 via app with 360° pan range.

Cameras

• Compatibility: Supports mirrorless and DSLR cameras up to 2 kg payload limit.
• Mount Type: Standard 1/4-inch screw with Arca-Swiss compatible plate.

Battery & Charging

• Battery: 2600 mAh 7.2 V 18.72 Wh Li-ion.
• Runtime: Up to 10 hours under standard load.
• Charging Port: USB-C at 5 V / 2 A delivering 10 W.
• Charge Time: 2.5 hours to full capacity.

Software & AI

• App Integration: DJI Mimo with ActiveTrack 4.0 and timelapse modes.
• Firmware: Over-the-air updates via Bluetooth.

Connectivity

• Wireless: Bluetooth 5.0 for smartphone pairing.
• Ports: USB-C for charging and firmware.

Colors

• Finish Options: Matte black with gray accents.
